Specifications
Dimensions
Width:540 mm (21”)
Length:1010 mm (39.5”)
Seat Width:430 – 500 mm (17” – 19”)
Seat Height:450 mm (17.5”)
Seat Depth:405 – 505 mm (16” – 20”)
Seat Tilt:0° – 6°
Backrest Height:500 mm (20”)
Back Recline:0°, 4°, 8° & 12° (manual)
Turning Radius:1600 mm (63”)
Performance/Weights
Max. Range:31 km (19 miles)
Speed:6 kph
Batteries:55 Ah
Maximum Safe Slope:6°
Max Kerb Climb:70 mm – 100 mm (with Kerb Climber)
Electronics:VR2
Min. Weight:from 95 kg (incl. 55 Ah batteries)
Maximum User Weight:125 kg
Transportation
Crash Tested?This product has been successfully crash tested and fulfils the performance requirements for ISO 7176-19
